INTELLI-POLE® Configuration Tool

Our unique sectional design is available in a variety of pole heights to provide you with safer & easier assembly, installation, interchange, and removal.

Please contact us to confirm the correct Intelli-Pole® configuration for your application, and to request a PDF of detailed engineering standards.

1 2

Section 4

Section 3

Section 2

Section 1 - Truncated

Exact Pole Length (1) Pole AGH (2) Weight (3) Tip OD Base OD Class using Grade C rules (4) Class using Grade B rules (4)
23.25 ft. 20.50 ft. 290 lbs. 9.80 in. 13.90 in. 4 3
30.00 ft. 25.00 ft. 520 lbs. 10.70 in. 15.30 in. 2 1
34.10 ft. 29.50 ft. 565 lbs. 9.80 in. 15.30 in. 2 1
40.00 ft. 34.00 ft. 795 lbs. 10.90 in. 16.20 in. 1 H2
45.00 ft. 38.50 ft. 850 lbs. 9.80 in. 16.20 in. 1 H2
7.087 m 6.248 m 132 kg 249 mm 353 mm 4 3
9.144 m 7.620 m 236 kg 272 mm 389 mm 2 1
10.401 m 8.992 m 256 kg 249 mm 389 mm 2 1
12.192 m 10.363 m 361 kg 277 mm 411 mm 1 H2
13.716 m 11.735 m 386 kg 249 mm 411 mm 1 H2

(1) Precise length of relevant Intelli-Pole® sections when assembled prior to installation.
(2) AGH is based upon a standard embedment assumption of 10% of the pole height plus 2 ft. [0.61 m], which may change depending upon soil conditions.
(3) Total weight of relevant Intelli-Pole® sections when assembled prior to installation.
(4) Pole class rating based upon National Electric Safety Code (NESC) rules for strength and load-bearing capacity, specified by category of intended pole use (i.e., Grade of construction).
